The SG-900 Multi Lane Back Sealing Granule Packaging Machine is designed for high-volume automatic packaging of free-flowing granular products. Equipped with 2 kepada 8 filling lanes, the machine can significantly increase production efficiency while maintaining precise dosing accuracy and consistent sealing quality.
It is widely used in food, pharmaceutical, nutraceutical, and chemical industries for packaging products such as sugar, coffee, salt, seasoning powder, desiccants, herbal granules, and instant beverage mixes.
The SG-900 is a fully automatic vertical form-fill-seal (VFFS) packaging system that performs bag forming, dosing, filling, sealing, cutting, and counting in one continuous process.
Its multi-lane design allows manufacturers to produce multiple sachets simultaneously, reducing labor costs and maximizing production output.
✔ Up to 8-lane simultaneous production
✔ Stable PLC control system
✔ High-speed servo film pulling
✔ Accurate volumetric dosing
✔ Compact machine footprint
✔ Low maintenance requirements
✔ Suitable for 24-hour continuous production
✔ Supports various sachet styles
| Item | Spesifikasi |
|---|---|
| Model | SG-900 |
| Packaging Speed | Up to 50 Bags/Min/Lane |
| Number of Lanes | 2–8 Lanes |
| Filling Range | 3–50ml |
| Bag Width | 25–100mm |
| Bag Length | 30–170mm |
| Bag Type | Back Seal Sachet |
| Cutting Type | Flat Cut, Zigzag Cut, Tooth Cut |
| Control System | PLC + Touch Screen |
| Sealing System | PID Intelligent Temperature Control |
| Film Feeding | Servo Driven |
| Power Supply | Customized |
The machine can produce a wide range of sachet styles:
Ideal for:
Suitable for:
Customized pouch formats are available according to customer requirements.
The SG-900 is compatible with most heat-sealable laminated films.
| Item | Spesifikasi |
|---|---|
| Max Film Width | 180mm |
| Max Roll Diameter | 300mm |
| Core Diameter | 76mm |
| Film Thickness | 0.05–0.10mm |
Multiple lanes operate simultaneously, greatly increasing packaging capacity compared to single-lane machines.
User-friendly interface enables easy parameter setting and production monitoring.
Ensures accurate film feeding and stable pouch dimensions.
Automatically detects printed registration marks for precise cutting and sealing.
Maintains stable sealing temperatures to ensure strong and attractive seals.
The SG-900 offers an ideal balance of speed, ketepatan, and reliability for manufacturers seeking large-scale sachet packaging solutions. Its modular multi-lane design makes it suitable for both medium and high-volume production environments.
Whether packaging sugar sticks, instant coffee sachets, herbal granules, or nutritional supplements, the SG-900 delivers consistent performance and excellent packaging quality.
The machine can be configured with 2, 4, 6, atau 8 lanes according to production requirements.
Sugar, salt, coffee granules, herbal granules, desiccants, seasonings, and other free-flowing granular materials.
ya. Stick packs, back-seal sachets, and customized pouch formats are available.
ya. The machine can be customized based on product specifications and packaging requirements.
